Key Clamp Handrail Bracket – 48.3mm

Key Clamp Handrail Bracket – 48.3mm

Provide a secure fixing point for wall-mounted handrails with our Key Clamp Handrail Bracket, designed for use with 48.3mm outside diameter tube. This heavy-duty 48.3mm key clamp handrail bracket is ideal for creating strong, professional handrail systems in commercial, industrial and public environments without the need for welding.

Manufactured from durable galvanised cast iron, this high-quality key clamp fitting offers excellent corrosion resistance for both indoor and outdoor installations. Unlike fittings that position the tube close to the wall, the handrail bracket projects the tube away from the mounting surface, providing sufficient clearance for users to comfortably wrap their hand around the rail. This makes it the ideal choice for handrails on stairways, ramps, walkways and other pedestrian access routes.

Compatible with standard 48.3mm galvanised tube, this fitting is commonly used in pedestrian handrails, safety barriers, access ramps, walkways and guardrail systems. The integrated socket grub screw allows the tube to be securely clamped in place using a standard Allen key, making installation quick, simple and easy to adjust if required.

As part of a modular key clamp system, this handrail bracket enables strong tubular structures to be assembled without specialist fabrication, providing a flexible solution that can easily be modified or extended in the future.

Key Features

• Handrail wall bracket for 48.3mm outside diameter tube
• Side-through design allows continuous handrail installation
• Manufactured from galvanised cast iron
• Suitable for internal and external applications
• Ideal for handrails, guardrails, ramps and walkways
• Corrosion-resistant finish
• Quick installation using an Allen key
• Compatible with modular 48.3mm key clamp systems

Please Note

Designed for use with 48.3mm outside diameter tube. Wall fixings are not included, allowing you to select the most appropriate fixing method for your installation surface. It is the installer’s responsibility to ensure the chosen fixings and mounting surface are suitable for the intended application and load. The customer is also responsible for ensuring this fitting is used for its intended purpose and that all socket grub screws are correctly tightened before use.
